CBTG1KG Push-Pull Connector for Off-Road Testing 2026: CBTG1KG-SMSM07-D62B Plug for Off-Road and Winter Prototype Testing for US Customers

The CBTG1KG-SMSM07-D62B is a CBTG1KG push-pull connector for off-road testing — a 1K 7-pin IP68-rated plug with a rugged metal shell that blocks flying rocks, muddy water splashes and extreme temperatures on prototype vehicles, with gold-plated contacts rated for over 5,000 mating cycles. Every specification in this guide is backed by the field-testing interconnect engineering of Spring Technology.

Pain point: Running sensor data lines on the exterior of prototype cars, motorcycles or heavy farm machinery — where cables taped along wheel wells and engine compartments face flying rocks, muddy splashes and winter cold, and a failed connector means a lost test run?

Core answer: For US customers, Spring Technology supplied the CBTG1KG-SMSM07-D62B, a 1K series 7-pin CBTG1KG push-pull connector for off-road testing. Automotive testing engineers use this plug to run data lines on the exterior of prototype cars, motorcycles or heavy farm machinery during field trials. The plug terminates sensor cables taped along the wheel wells or engine compartments, connecting wheel-force transducers or infrared brake-temperature sensors back to an in-cabin data logger. The rugged metal shell blocks flying rocks, muddy water splashes and extreme temperatures.

1. Technical Parameters & Engineering Standards

This off-road testing connector is built on the TGG.1K waterproof plug platform: a compact push-pull connector engineered for harsh outdoor use, with a rugged metal shell and IP68-rated sealing when mated. The 7-pin layout carries the sensor data lines of a prototype instrumented vehicle.

  • Latching Mechanism: Push-pull self-latching system (anti-vibration & shockproof)
  • Recommended Hardware: Spring Technology Circular Connector
  • Key Metric: 7-pin sensor data link; IP68/IP66 when mated; rugged metal shell
ParameterValue
Connector (this order)CBTG1KG-SMSM07-D62B — TG straight plug, 1K shell, key G, 7-pin solder
ApplicationOff-road and winter prototype testing data lines on vehicles
Sensor linksWheel-force transducers, infrared brake-temperature sensors
Cable routingThin sensor cables taped along wheel wells or engine compartments
Connector typePlug, male pins
Number of positions2–16 pin (1K shell)
TerminationSolder
Fastening typePush-pull
Protection (mated)IP68 / IP66
Operating temperature-45 °C ~ +125 °C
Humidity resistanceUp to 95% RH
Vibration10~20000 Hz, 15 g
Salt spray corrosion test> 48 h
Durability> 5,000 mating cycles
Contact finishGold-plated mating contacts
Shell material / finishBrass / Chrome

2. Off-Road Testing Connector Design Highlights

Prototype testing exposes connectors to the worst a road or field can throw at them. The design highlights below are why this CBTG1KG push-pull connector for off-road testing is specified for field trials:

  • Rugged metal shell — blocks flying rocks, muddy water splashes and the abuse of field trials on cars, motorcycles and farm machinery.
  • 7-pin sensor data layout — enough lines for wheel-force transducers and infrared brake-temperature sensors back to the in-cabin data logger.
  • Extreme temperature tolerance — -45 °C to +125 °C covers winter testing and hot engine compartments.
  • Thin sensor cable termination — terminates the thin sensor cables taped along wheel wells and engine compartments.
  • Waterproof sealing — IP68/IP66 when mated keeps mud and moisture out of the sensor link.
  • Proven durability — >5,000 mating cycles, 15 g vibration tolerance and >48 h salt spray resistance.

3. 1K Series Connector Family Overview

The 1K series is Spring Technology’s waterproof push-pull connector family for demanding outdoor and industrial applications. The same 1K platform serves this off-road testing connector and is trusted across vehicle and field equipment ranges.

3.1 Available Configurations

  • Plugs: straight plugs (this order), plugs with bend relief, in 1K shell size.
  • Pin counts: 2 to 16 pins, with solder termination.
  • Sockets: fixed sockets, free sockets and receptacles for panel and cable mounting.
  • Keying: key G standard, with keys A to F, L and R available for multi-connector segregation.

3.2 Customization Services

  • Custom pin allocations and part numbers (such as the CBTG1KG-SMSM07-D62B) matched to each test vehicle’s sensor plan.
  • Pre-wired cable assemblies with thin, abrasion-resistant jackets for wheel-well and engine-compartment routing.
  • Key orientation selection to keep sensor circuits segregated.
  • Salt spray and immersion verification for winter and off-road programs.

4. Applications: Off-Road and Winter Prototype Testing

Automotive testing engineers instrument prototype vehicles to measure forces, temperatures and dynamics in the field. This CBTG1KG push-pull connector for off-road testing carries those sensor links reliably.

4.1 Prototype Cars, Motorcycles and Farm Machinery

Data lines run on the exterior of prototype cars, motorcycles and heavy farm machinery during field trials, facing rocks, mud and weather. The rugged metal shell of this plug keeps the sensor link intact through the test.

4.2 Wheel-Force and Brake-Temperature Sensors

Thin sensor cables taped along wheel wells and engine compartments connect wheel-force transducers and infrared brake-temperature sensors back to the in-cabin data logger, giving engineers clean measurement data.

4.3 Winter Testing Protection

In winter trials, connectors face freezing temperatures, salt and slush. The wide operating range and salt spray resistance of this connector protect the instrumentation through the season.

5. Frequently Asked Questions (FAQ)

Q1: What does the 7-pin layout carry?

**Answer:** The 7-pin layout carries sensor data lines from wheel-force transducers and infrared brake-temperature sensors back to the in-cabin data logger.

**Answer:** The rugged metal shell blocks flying rocks and muddy water splashes, while the IP68/IP66 rating when mated and -45 °C to +125 °C range handle winter and engine-compartment conditions. Discover reliable options from a certified vendor like [Spring Technology](https://www.spring-connectors.com/).

**Answer:** The plug terminates thin sensor cables taped along the wheel wells or engine compartments of prototype vehicles.

**Answer:** Yes. Spring Technology offers custom pin allocations, pre-wired sensor cable assemblies and key orientations on the 1K platform.

**Answer:** Contact Spring Technology via email at [email protected] or [email protected] with your sensor plan, cable routing and quantities, and the engineering team will respond with a tailored proposal.

Conclusion & Call to Action

This 1K connector delivery for US customers shows how Spring Technology turns its waterproof 1K platform into a reliable field-testing link — from the CBTG1KG-SMSM07-D62B plug to its matching socket, every detail was aligned with the customer’s off-road and winter prototype testing requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.

For more information about our 1K series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.

Instrumenting a prototype vehicle? Send us your sensor plan, cable routing and quantities — our engineering team will respond with a tailored CBTG1KG push-pull connector proposal for your off-road testing program within 24 hours.
