CBTG1BG Push-Pull Connector for Video Borescope Processors 2026: 1B Series 8-Contact 1 Gb/s Ethernet Connector for Industrial Inspection Equipment

The CBTG1BG-SMSM08-D72B is a CBTG1BG push-pull connector for video borescope processors — an 8-contact 1B series connector supporting 1000 Base-T4 Gigabit Ethernet transmission through four differential pairs at up to 1 Gb/s, with a 5 A rated current, low contact resistance, shielded construction and up to 5,000 mating cycles. Every specification in this guide is backed by the industrial inspection interconnect engineering of Spring Technology.

Pain point: Streaming inspection video out of an industrial video borescope processor — where the imaging module, camera head and processing unit must exchange Gigabit-class image data through a connector that also survives constant transport, cable changes and electrically noisy plant environments?

Core answer: Spring Technology supplies the CBTG1BG-SMSM08-D72B, an 8-contact 1B series connector serving as a CBTG1BG push-pull connector for video borescope processors. An industrial video borescope processor receives, processes, displays and records images captured from an inspection probe or camera, and such systems are widely used for inspecting engines, turbines, pipelines, machinery, castings and welds where direct visual inspection is difficult. The processor must handle high-speed image data while communicating with the camera or inspection probe and providing control or auxiliary interfaces, so the connector provides eight low-voltage contacts arranged as four high-speed differential pairs with 1000 Base-T4 support at up to 1 Gb/s — an architecture particularly relevant to compact Gigabit Ethernet connectivity.

1. Technical Parameters & Engineering Standards

This borescope connector is built on the 1B series push-pull platform, a compact circular connector family for professional inspection and data equipment.

  • Latching Mechanism: Push-pull self-latching system (locks by pushing into the mating receptacle)
  • Recommended Hardware: Spring Technology Circular Connector
  • Key Metric: 4 high-speed differential pairs; 1000 Base-T4 up to 1 Gb/s; 5 A rated current; max. 6.1 mΩ contact resistance
ParameterValue
Connector (this order)CBTG1BG-SMSM08-D72B — TG plug, 1B shell, key G, 8 contacts
Contacts8 low-voltage contacts arranged as four high-speed differential pairs
Data transmission1000 Base-T4 Gigabit Ethernet, up to 1 Gb/s with CAT 5e cable technology
Rated current5 A
Contact resistanceMax. 6.1 mΩ
ShieldingMin. 75 dB at 10 MHz, 40 dB at 1 GHz
Mating cyclesUp to 5,000 mating cycles
Shell size1B (compact size)
Housing materialChrome-plated brass housing (chrome shell)
Cable retentionCable collet for cable fixation and bend-relief protection
Vibration resistance10~20000 Hz, 15 g
Shock resistance100 g · 6 ms
ProtectionIP50 (1B series platform, mated)
Operating temperature-45 °C ~ +125 °C (1B series platform)

2. Video Borescope Connector Design Highlights

Inspection processors move between engines, pipes and plant floors. The design advantages below explain why this CBTG1BG push-pull connector for video borescope processors suits industrial inspection equipment:

2.1 1 Gb/s High-Speed Data Transmission

  • The connector supports 1000 Base-T4 Gigabit Ethernet with four high-speed differential pairs and data transmission speeds of up to 1 Gb/s using CAT 5e cable technology. For a borescope processor, high-speed transmission matters when transferring camera images and inspection video between the imaging system and processing unit — a Gigabit-capable interface provides sufficient bandwidth for demanding digital video while keeping a compact circular connector format.

2.2 Push-Pull Locking for Fast Equipment Connection

  • Industrial inspection equipment is frequently assembled, transported and reconfigured. The push-pull self-latching system lets operators connect and disconnect the cable quickly without a threaded coupling, and the connector locks simply by being pushed into the mating receptacle — making probe or cable replacement more convenient and reducing connection time during repeated inspection operations.

2.3 Eight Contacts Integrate Multiple Functions

  • With 8 low-voltage contacts, four differential pairs can carry 1000 Base-T4 high-speed communication, letting designers use a single compact interface instead of several separate connectors. For compact inspection processors, reducing external connector count simplifies cable management and equipment integration.

2.4 Shielding Protects High-Speed Signals

  • Industrial inspection environments may contain motors, generators, power electronics and test equipment. Shielding performance specified at 75 dB at 10 MHz and 40 dB at 1 GHz helps equipment designers manage electromagnetic interference around high-speed communication interfaces — important because interference on a high-speed data link can affect communication stability and system performance.

2.5 Low Contact Resistance

  • A maximum specified electrical contact resistance of 6.1 mΩ helps maintain stable electrical performance at the connector interface, benefiting inspection equipment that needs reliable connections for both communication and auxiliary electrical functions.

2.6 Designed for Frequent Mating Cycles

  • Borescope equipment is used across multiple inspection locations and may need the probe or cable assembly connected and disconnected repeatedly. A specification of 5,000 mating cycles suits professional equipment with replaceable cables or removable probes, where durability is an important consideration.

2.7 Compact 1B Connector Size

  • The 1B size provides a relatively compact interface for professional electronic equipment. Processors must balance processing electronics, display interfaces, storage, power systems and external connections within a limited enclosure, and a compact circular connector keeps the external interface clean while retaining the mechanical advantages of a metal push-pull connector.

2.8 Mechanical Protection for Mobile Inspection Equipment

  • The chrome-plated brass housing and cable collet designed for cable fixation and bend-relief protection suit equipment that is frequently transported and handled. The connector is also specified for 100 g shock resistance and 15 g vibration resistance, adding mechanical performance for professional applications.

2.9 Wide Temperature Capability

  • The 1B connector platform specifies a temperature range of -45 °C to +125 °C, providing additional design margin for industrial inspection applications. The actual operating temperature of a complete borescope system must still be determined by the limits of the camera, electronics, cable, housing and other components rather than by the connector specification alone.

3. 1B Series Connector Family Overview

The 1B shell is part of Spring Technology’s push-pull self-locking connector family, used in professional imaging, industrial inspection, control and test equipment. The same platform serves this borescope connector and scales across pin counts and termination variants.

3.1 Available Configurations

  • Shell: 1B shell size, with 0B and 2B siblings for smaller or larger layouts.
  • Pin counts: 2 to 16 contacts, including the 8-contact four-differential-pair configuration.
  • Termination: solder termination with cable collet and bend relief options.
  • Materials: chrome-plated brass housings with shielded structures across the platform.

3.2 Customization Services

  • Custom contact allocations and part numbers (such as the CBTG1BG-SMSM08-D72B) matched to each processor’s data and power plan.
  • Gigabit Ethernet cable assembly design with CAT 5e-class cabling.
  • Shielding and EMC verification for high-speed links.
  • Pre-wired camera head and processor harnesses.

4. Applications: Industrial Video Borescope Processors

Inspection systems depend on high-speed links that hold up in the field. This CBTG1BG push-pull connector for video borescope processors serves the imaging chain.

4.1 Inspection Camera or Imaging Module to Processor

The Gigabit Ethernet interface carries image data from the inspection probe or camera into the processing unit over four differential pairs.

4.2 Camera Head and Processing Unit Links

Camera head connections use the same compact connector, supporting quick probe or cable replacement between inspection jobs.

4.3 Processor to External Control and Auxiliary Interfaces

External control equipment, high-speed data modules and auxiliary power interfaces share the 8-contact layout, with pin assignment set by the manufacturer’s design.

5. Frequently Asked Questions (FAQ)

Q1: What data rate does the connector support?

**Answer:** It supports 1000 Base-T4 Gigabit Ethernet through four high-speed differential pairs at up to 1 Gb/s using CAT 5e cable technology, providing sufficient bandwidth for digital video and inspection data in a compact circular connector format.

**Answer:** The push-pull self-latching system locks simply by pushing the connector into the mating receptacle and disconnects without a threaded coupling, making probe or cable replacement more convenient during inspection work. Discover reliable options from a certified vendor like [Spring Technology](https://www.spring-connectors.com/).

**Answer:** Four of the 8 low-voltage contacts form differential pairs for 1000 Base-T4 communication, letting a single compact interface replace several separate connectors and simplifying cable management.

**Answer:** Shielding is specified at 75 dB at 10 MHz and 40 dB at 1 GHz, helping designers manage electromagnetic interference from motors, generators and power electronics around high-speed data links.

**Answer:** Maximum specified contact resistance is 6.1 mΩ with a 5 A rated current, maintaining stable electrical performance for both communication and auxiliary functions.

**Answer:** The connector is specified for up to 5,000 mating cycles, suitable for inspection equipment with replaceable cables or removable probes used across multiple inspection locations.

**Answer:** The chrome-plated brass housing and cable collet provide cable fixation and bend-relief protection, while 100 g shock resistance and 15 g vibration resistance add mechanical performance for mobile inspection equipment.

**Answer:** The 1B connector platform specifies -45 °C to +125 °C; the actual operating temperature of a complete borescope system must be determined by the camera, electronics, cable and housing limits rather than by the connector specification alone.

Conclusion & Call to Action

This 1B connector delivery shows how Spring Technology serves industrial inspection equipment — from the four differential pairs and 1 Gb/s Ethernet support of the CBTG1BG-SMSM08-D72B to its chrome-plated brass housing and cable collet, every detail was aligned with the customer’s video borescope processor requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.

For more information about our 1B series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.

Building a borescope processor or inspection camera system? Send us your data and power requirements — our engineering team will respond with a tailored CBTG1BG push-pull connector proposal for your video borescope processors within 24 hours.
