CBTG1BG Connectors for Electrostatic Spray Coating Controllers 2026: 1B 4-Contact and 5-Contact Cable Plugs

The CBTG1BG-SMSM04-D52B and CBTG1BG-SMSM05-D620 are CBTG1BG connectors for electrostatic spray coating controllers — 1B straight cable plugs with four and five low-voltage contacts, published rated currents of 10 A and 9 A respectively, push-pull locking, cable collet fixation, a specified cable outside diameter range of 4.30–5.20 mm, IP50 protection, solder termination and a published mating endurance of 5,000 cycles. Every specification in this guide is backed by the industrial coating equipment interconnect engineering of Spring Technology.

Pain point: Wiring the low-voltage control and signal side of a spray coating controller — where circuit counts vary between machine variants, cables are replaced during servicing, the cable must stay clearly separate from the applicator’s high-voltage circuits, and the interface must never be mistaken for a spray-voltage connection?

Core answer: Spring Technology offers these connectors as potential options for suitable low-voltage control and signal interfaces, supporting push-pull locking, multiple contact configurations, compact cable connections and convenient maintenance for industrial coating equipment. Industrial electrostatic spray coating systems are used in automotive manufacturing, metal finishing, furniture production and other industrial coating processes, controlling spraying parameters and coordinating spray applicator operation to help achieve consistent coating quality. A typical controller manages spray voltage settings, operating modes, system status and communication with other equipment — and depending on the system architecture, electrical interfaces may connect the controller to external control panels, monitoring devices or compatible auxiliary modules. These connectors should only be used in circuits for which their ratings and environmental characteristics are suitable, and they are not intended to replace the dedicated high-voltage connections required by electrostatic spray applicators.

1. Technical Parameters & Engineering Standards

Both connectors are built on the TG 1B straight plug platform, a compact circular connector family for industrial control equipment.

  • Latching Mechanism: Push-pull locking mechanism (a compatible plug connects and releases without repeatedly rotating a threaded coupling)
  • Recommended Hardware: Spring Technology Circular Connector and custom cable assembly service
  • Key Metric: 4 and 5 low-voltage contacts; 10 A and 9 A published ratings; IP50; 5,000 mating cycles

1.1 Four-Contact vs Five-Contact Comparison

FeatureCBTG1BG-SMSM04-D52BCBTG1BG-SMSM05-D620
Contacts4 low-voltage contacts5 low-voltage contacts
Published rated current10 A9 A
Documented data capabilityUSB 2.0 (per model documentation)Confirm per model documentation
BodyTG 1B straight cable plugTG 1B straight cable plug
Cable fixationCable colletCable collet
LockingPush-PullPush-Pull
Mating endurance5,000 cycles5,000 cycles

1.2 Shared 1B Platform Specifications

ParameterValue
SeriesTG 1B straight cable plug
Cable outside diameter4.30–5.20 mm (as specified); 1B platform opening range 2.2–7.5 mm
Pin counts available2–16 pins across the 1B shell
ProtectionIP50
Operating temperature-45 °C ~ +125 °C (1B platform)
Vibration resistance10~20000 Hz, 15 g
Shock resistance100 g · 6 ms
HousingChrome-plated brass shell with PPS insulator

Note: the published ratings should not be interpreted as a guarantee that every contact can carry the maximum rated current simultaneously under all operating conditions — actual current capacity depends on the manufacturer’s derating guidance, conductor dimensions, ambient temperature, contact loading and the electrical design.

2. Connector Design Highlights for Spray Coating Controllers

Coating lines run hard and are serviced on schedule. The design advantages below explain why these CBTG1BG connectors for electrostatic spray coating controllers suit low-voltage control interfaces:

2.1 Multiple Contacts for Control and Signal Connections

  • Four low-voltage contacts in the CBTG1BG-SMSM04-D52B and five in the CBTG1BG-SMSM05-D620 let equipment designers choose a connector based on the number of electrical circuits required. For a coating controller, suitable circuits might include auxiliary control signals, status feedback or other low-voltage connections: the four-contact version suits a simpler interface, while the five-contact version provides an additional contact for designs needing another circuit. The actual pin assignment must be defined by the equipment manufacturer.

2.2 Push-Pull Locking for Convenient Maintenance

  • Industrial coating equipment requires regular inspection, cable replacement and maintenance. The push-pull locking mechanism lets a compatible plug be connected and released without repeatedly rotating a threaded coupling, simplifying routine cable handling and helping technicians disconnect suitable interfaces during servicing. Correct mating and proper operating procedures remain essential for reliable use.

2.3 Cable-Mounted Design for Flexible Equipment Layouts

  • Both models are straight cable plugs with cable collet fixation and a specified cable outside diameter range of 4.30–5.20 mm. This construction supports organised cable routing between a controller and compatible external equipment, and a suitable cable assembly keeps connections accessible during installation and troubleshooting. Engineers should confirm cable dimensions, conductor size, strain relief and routing requirements before choosing the final assembly.

2.4 Different Current Ratings for Different Circuit Requirements

  • The published rated current is 10 A for the four-contact model and 9 A for the five-contact model — useful reference values when evaluating compatible low-voltage circuits, provided the derating guidance, conductor dimensions, ambient temperature and contact loading are respected.

2.5 Repeatable Connections During Equipment Service

  • The published specifications list a mating endurance of 5,000 cycles for these models — useful where compatible cables are connected and disconnected repeatedly during maintenance or configuration changes. A properly selected connector interface helps standardise cable connections across compatible controller assemblies, while installation quality, handling and adherence to the specified operating conditions remain important for long-term performance.

2.6 Shielding Support for Industrial Control Interfaces

  • The published specifications list shielding performance for both models. In an industrial control system, suitable shielding and grounding help manage electromagnetic interference affecting compatible signal circuits; the actual result depends on the complete cable assembly, connector termination, grounding arrangement and equipment layout. In electrostatic spray systems, engineers must also follow the controller manufacturer’s electrical safety instructions and separation requirements for high-voltage circuits.

3. Four-Contact vs Five-Contact Models

The primary difference between these models is the number of contacts and the corresponding electrical ratings. The four-contact model may be considered where a compatible four-contact interface is sufficient, while the five-contact model suits circuit designs requiring an additional contact.

  • CBTG1BG-SMSM04-D52B: four contacts, rated current of 10 A, and documented USB 2.0 capability.
  • CBTG1BG-SMSM05-D620: five contacts, rated current of 9 A.

Although the four-contact model is listed for USB 2.0, this capability should not be assumed for the five-contact model or for a complete system without checking the relevant device documentation.

4. Important Design Considerations

Before integrating either of these CBTG1BG connectors for electrostatic spray coating controllers into a coating controller, engineers should verify:

  • The required contact count and electrical pin assignment
  • Compatibility with the exact mating receptacle
  • Operating voltage, current and conductor specifications
  • Cable outside diameter and cable collet compatibility
  • Environmental protection requirements for dust, moisture and cleaning procedures
  • Grounding, shielding and separation from high-voltage circuits
  • Whether the IP50 rating is suitable for the installation environment

These checks help ensure that the selected connector is appropriate for the intended interface and does not compromise the safety requirements of the coating system.

5. Applications: Industrial Coating Equipment

These are potential engineering applications for these CBTG1BG connectors for electrostatic spray coating controllers, based on the connector configuration — not verified installations in specific equipment brands or models:

5.1 Electrostatic Spray Coating Controllers

Low-voltage control and signal interfaces in industrial electrostatic spray coating controllers.

5.2 External Control Panels and Monitoring Devices

Cable connections between coating controllers and external control panels, monitoring devices or auxiliary modules.

5.3 Metal Finishing and Furniture Coating Lines

Coating equipment used in automotive manufacturing, metal finishing and furniture production processes.

6. Frequently Asked Questions (FAQ)

Q1: How do the two models differ?

**Answer:** In contact count and rating — the CBTG1BG-SMSM04-D52B has four contacts at 10 A with documented USB 2.0 capability, while the CBTG1BG-SMSM05-D620 has five contacts at 9 A.

**Answer:** No — they are intended for suitable low-voltage control and signal circuits only and are not a replacement for the dedicated high-voltage connections required by electrostatic spray applicators. Discover reliable options from a certified vendor like [Spring Technology](https://www.spring-connectors.com/).

**Answer:** No — the published ratings are reference values and do not guarantee maximum current on every contact simultaneously; capacity depends on derating guidance, conductor dimensions, ambient temperature and contact loading.

**Answer:** That capability is documented for the four-contact model only; it should not be assumed for the five-contact model or for a complete system without checking the relevant device documentation.

**Answer:** A specified cable outside diameter range of 4.30–5.20 mm with collet fixation, within the 1B platform opening range of 2.2–7.5 mm.

**Answer:** It depends on the installation — dust, moisture and cleaning procedures must be evaluated, since IP50 is not a waterproof rating and additional system-level protection may be required.

**Answer:** Contact count and pin assignment, mating receptacle compatibility, voltage and current requirements, cable dimensions, environmental protection, and grounding plus separation from high-voltage circuits. Contact [email protected] to review your design.

Conclusion & Call to Action

This 1B connector delivery shows how Spring Technology serves industrial coating equipment — from the four 10 A contacts of the CBTG1BG-SMSM04-D52B to the five 9 A contacts of the CBTG1BG-SMSM05-D620, with cable collet fixation and push-pull locking on both, every detail was aligned with the customer’s electrostatic spray coating controller requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.

For more information about our 1B series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.

Building an electrostatic spray coating controller or coating line control panel? Send us your circuit and cabling requirements — our engineering team will respond with a tailored CBTG1BG connectors proposal for your electrostatic spray coating controllers within 24 hours.
