Push-Pull Connector for Industrial Sensors 2026: CBTG1BG-SMSM05-D52B and CBTG1BG-SMSM06-D62B for Multi-Axis Sensors for Russian Client
The CBTG1BG-SMSM05-D52B and CBTG1BG-SMSM06-D62B are 1B push-pull connector for industrial sensorss — a 5-pin variant for load cells and pressure transducers, and a 6-pin variant for encoders, stepper controllers and automated grippers — built on a push-pull platform rated for over 5,000 mating cycles with gold-plated contacts. Every specification in this guide is backed by the precision interconnect engineering of Spring Technology.
Pain point: Wiring multi-axis industrial sensors — load cells, pressure transducers, encoders and gripper actuators — where every signal line must stay clean, every shield must be grounded, and a loose connector on a vibrating machine means lost data or a stopped production line?
Core answer: Spring Technology supplied a Russian client with two 1B series push-pull connector for industrial sensors variants: the CBTG1BG-SMSM05-D52B 5-pin plug for high-accuracy load cells or pressure transducers, carrying Power (+), Ground (−), Signal (+), Signal (−) plus an internal ground/shield line; and the CBTG1BG-SMSM06-D62B 6-pin plug for encoders, stepper motor controllers or automated grippers, adding extra lines for differential signaling such as RS-485, CAN bus or clock/data loops.
1. Technical Parameters & Engineering Standards
Both variants share the TGG.1B straight plug platform: a compact push-pull connector with 2 to 16 pin capability, gold-plated mating contacts and a chrome-plated brass shell. The 5-pin and 6-pin configurations in this order cover the two most common signal architectures in multi-axis sensor systems.
- Latching Mechanism: Push-pull self-latching system (anti-vibration & shockproof)
- Recommended Hardware: Spring Technology Circular Connector
- Key Metric: 5-pin standard sensor wiring or 6-pin differential signaling; >5,000 mating cycles; gold-plated contacts
| Parameter | Value |
|---|---|
| Plug A (this order) | CBTG1BG-SMSM05-D52B — TG straight plug, 1B shell, key G, 5-pin solder |
| Plug B (this order) | CBTG1BG-SMSM06-D62B — TG straight plug, 1B shell, key G, 6-pin solder |
| Pin allocation (5-pin) | Power (+), Ground (−), Signal (+), Signal (−), internal ground/shield |
| Pin allocation (6-pin) | Adds differential signaling lines: RS-485, CAN bus, or clock/data loops |
| Connector type | Plug, male pins |
| Number of positions | 2–16 pin (1B shell) |
| Termination | Solder |
| Fastening type | Push-pull |
| Protection level | IP50 |
| Operating temperature | -45 °C ~ +125 °C |
| Humidity resistance | Up to 95% RH at 60 °C |
| Vibration / shock | 10~20000 Hz, 15 g / 100 g·6 ms |
| Salt spray corrosion test | > 48 h |
| Durability | > 5,000 mating cycles |
| Contact finish | Gold-plated mating contacts |
| Shell material / finish | Brass / Chrome |
2. Industrial Sensor Connector Design Highlights
Industrial sensors are only as reliable as their wiring. The design highlights below are why this 1B push-pull connector for industrial sensors is specified for multi-axis measurement and motion systems:
- Dedicated 5-pin sensor wiring — Power (+), Ground (−), Signal (+), Signal (−) plus an internal ground/shield line give load cells and pressure transducers a clean, shielded path for high-accuracy readings.
- 6-pin differential signaling — extra lines support RS-485, CAN bus or clock/data loops for encoders, stepper motor controllers and automated grippers in multi-axis systems.
- Gold-plated mating contacts — stable, low-resistance connections that preserve millivolt-level sensor signals.
- Push-pull self-latching — fast connect and disconnect for maintenance, with a lock that holds under 15 g vibration on moving machinery.
- Proven durability — >5,000 mating cycles and 100 g·6 ms shock tolerance for the daily demands of industrial floors.
- Wide temperature range — -45 °C to +125 °C suits unheated workshops, machine enclosures and production areas.
3. 1B Series Connector Family Overview
The 1B series is Spring Technology’s mid-size push-pull connector family, a popular choice for industrial sensing and control because it balances contact capacity with panel space. The same 1B platform covers both variants in this order, simplifying spare parts across the customer’s sensor fleet.
3.1 Available Configurations
- Plugs: straight plugs (this order), plugs with bend relief, elbow plugs, fixed plugs, in 1B shell size.
- Pin counts: 2 to 16 pins, with solder or PCB termination options.
- Sockets: fixed sockets (ZGG/ZCG/ZEG), PCB-contact sockets, free sockets, for panel and cable mounting.
- Keying: key G standard, with keys A–M and R available for multi-connector panels.
3.2 Customization Services
- Custom pin allocations and part numbers (such as the CBTG1BG-SMSM05-D52B and CBTG1BG-SMSM06-D62B) matched to each sensor’s signal plan.
- Pre-wired cable assemblies with shielding, braided or foil, for noisy industrial environments.
- Key orientation selection to prevent mismating where several connectors share one machine.
- Sealing and shell finish options for washdown and outdoor installations.
4. Applications: Industrial Multi-Axis Sensors
Multi-axis systems depend on connectors that deliver clean power and signals to every sensor and actuator on the machine. These two 1B push-pull connector for industrial sensors variants cover the standard wiring architectures used across industrial automation.
4.1 Load Cells and Pressure Transducers
High-accuracy load cells and pressure transducers output low-level signals that must travel unspoiled to the controller. The 5-pin configuration with its dedicated shield line keeps Power, Ground and differential Signal pairs clean, protecting measurement accuracy in weighing and force-control systems.
4.2 Encoders and Stepper Motor Controllers
Encoders and stepper controllers need clock/data or fieldbus lines in addition to power. The 6-pin variant provides the extra conductors for RS-485, CAN bus or clock/data loops, keeping position and motion data flowing reliably between the controller and the drive.
4.3 Automated Grippers and Multi-Axis Stations
Automated grippers and multi-axis stations mix sensors and actuators on one machine. Standardizing on the 1B push-pull connector for industrial sensors platform with 5-pin and 6-pin variants gives engineers one connector family for both measurement and motion signal groups, simplifying cabling and maintenance.
5. Frequently Asked Questions (FAQ)
Conclusion & Call to Action
This 1B push-pull connector for industrial sensors delivery for the Russian client shows how Spring Technology turns its compact 1B platform into a complete wiring standard for multi-axis sensing — from the CBTG1BG-SMSM05-D52B 5-pin plug to the CBTG1BG-SMSM06-D62B 6-pin plug, every detail was aligned with the customer's load cell, encoder and gripper signal requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.
For more information about our 1B series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.
Building a multi-axis sensing system? Send us your pin allocation, cable length and sensor types — our engineering team will respond with a tailored push-pull connector for industrial sensors proposal within 24 hours.
