CBZC2BG Push-Pull Connector for AOI Image Acquisition Systems 2026: 2B Series 19-Contact PCB Socket for Inspection Synchronization Units

The CBZC2BG-SFEM19-0000 is a CBZC2BG push-pull connector for AOI image acquisition systems — a 2B series fixed-panel socket with 19 low-voltage contacts, elbow (right-angle) PCB termination, push-pull self-locking, IP50 protection, 5,000 mating cycles, shielding of at least 75 dB at 10 MHz, a contact-to-contact test voltage of 1.4 kV DC and a contact-to-shell test voltage of 1.8 kV DC. Every specification in this guide is backed by the automated inspection equipment interconnect engineering of Spring Technology.

Pain point: Getting camera triggers, lighting synchronisation and status signals out of a compact AOI control unit — where a straight connector layout would consume too much space behind the panel, image electronics sit next to switching circuits and lighting drivers, and modules are swapped during scheduled service?

Core answer: Spring Technology supplies the CBZC2BG-SFEM19-0000, a panel-mounted interface that can be evaluated for AOI image acquisition and synchronization control units, supporting compact PCB integration, secure push-pull locking and organised signal connections. Automated optical inspection systems are widely used in electronics manufacturing to identify soldering defects, component misalignment, missing parts and other production quality issues. Inside an AOI machine, the image acquisition and synchronization control unit coordinates signals between industrial cameras, lighting controllers, trigger circuits and the system’s main processing board — connection points where 19 low-voltage contacts provide multiple paths in one compact circular connector, and elbow PCB termination supports integration with a board behind the equipment panel.

This AOI connector is built on the ZCG.2B fixed socket platform with elbow contacts, a mid-size circular connector family for professional equipment panels.

• Latching Mechanism: Push-pull self-locking mechanism (quick mating and unmating without a threaded coupling operation)
• Recommended Hardware: Spring Technology Circular Connector
• Key Metric: 19 low-voltage contacts; elbow PCB termination; 1.4 kV DC / 1.8 kV DC test voltages; IP50; 5,000 mating cycles

Note: the test-voltage ratings should be assessed against the equipment’s operating conditions, and the connector should be chosen after verifying pin assignment, signal characteristics, mating cable connector, mechanical clearances, shielding strategy and environmental conditions. IP50 does not mean the connector is waterproof — additional protection is necessary if the application is exposed to liquids or conductive dust.

Inspection machines live on repeatable, synchronised signal flow. The design advantages below explain why this CBZC2BG push-pull connector for AOI image acquisition systems suits acquisition and synchronization control units:

• An AOI image acquisition unit may need to connect trigger signals, control signals, status feedback and other low-voltage circuits. Nineteen low-voltage contacts offer multiple connection paths through a single connector interface, reducing the need for several separate connectors depending on the system’s electrical architecture and simplifying panel layout and cable management.

• Elbow PCB contacts are designed for printed circuit board integration, with right-angle termination that is useful when a straight connector layout would consume too much space behind the front or rear panel. In compact AOI control units the arrangement helps engineers plan the connector position around the main processing board, camera interface circuitry and lighting synchronization electronics.

• AOI machines require maintenance, calibration and replacement of electronic modules. The push-pull self-locking mechanism supports quick mating and unmating without relying on a threaded coupling operation, making it easier for technicians to disconnect a compatible cable assembly when servicing an image acquisition unit or replacing a control module — while keeping the connection secure during normal operation.

• Specified for 5,000 mating cycles, the connector suits equipment undergoing recurring service, inspection or module replacement. For manufacturers building AOI platforms intended for long-term industrial use, connector endurance is one factor when planning maintenance intervals and lifecycle costs.

• AOI equipment combines sensitive image acquisition electronics with switching circuits, lighting drivers, motors and other potential sources of electrical interference. Published shielding specifications of at least 75 dB at 10 MHz and 40 dB at 1 GHz support electromagnetic compatibility planning when the connector is integrated into a properly designed, shielded system. Actual noise performance depends on the complete assembly, including cable shielding, grounding, PCB layout and enclosure design.

• With an IP50 rating, the connector is a potential option for indoor equipment installed in a protected environment. It also has a specified contact-to-contact test voltage of 1.4 kV DC and contact-to-shell test voltage of 1.8 kV DC. These ratings should be assessed against the equipment’s operating conditions and electrical requirements, and IP50 does not mean the connector is waterproof.

When designing an automated optical inspection platform, engineers must balance signal connectivity, PCB packaging, maintenance efficiency and long-term reliability. The CBZC2BG-SFEM19-0000 combines 19 low-voltage contacts, elbow PCB termination, Push-Pull locking and a compact panel-mounted format:

• 19 low-voltage contacts for multi-signal connections in one interface
• Elbow PCB termination for compact board integration
• Push-Pull self-locking for convenient maintenance
• Specified endurance of 5,000 mating cycles
• Shielding and test-voltage data to support interface planning

These features make it a candidate for evaluation in AOI image acquisition and synchronization control units where a detachable multi-contact interface is required. Before selecting the connector, engineers should verify the required pin assignment, signal characteristics, mating cable connector, mechanical clearances, shielding strategy and environmental conditions.

The 2B shell belongs to Spring Technology’s push-pull connector family for inspection, instrumentation and professional equipment panels. The same platform serves this CBZC2BG push-pull connector for AOI image acquisition systems and scales across pin counts and contact variants.

• Sockets: ZCG.2B fixed sockets including the elbow contact version in this order, plus straight PCB contact versions.
• Pin counts: 2–26 contacts across the 2B shell, including the 19-contact layout.
• Termination: PCB contacts (straight and elbow), solder and cable-mount options.
• Mounting: fixed panel rear-mounted installation with keying to prevent mismating.

• Custom contact allocations and part numbers (such as the CBZC2BG-SFEM19-0000) matched to each system’s circuit plan.
• Panel cutout and PCB footprint customization for compact control units.
• Shielding and EMC verification for image acquisition and trigger circuits.
• Mating plug selection support, including keying and contact-layout confirmation.

These are potential application scenarios based on the connector’s published configuration, not verified installations in specific manufacturers’ equipment:

AOI camera trigger and image acquisition control units and PCB inspection machine synchronization interfaces.

Multi-camera inspection system control panels and electronic assembly inspection equipment.

Industrial machine vision signal interface modules requiring a detachable multi-contact panel interface.

This 2B connector delivery shows how Spring Technology serves automated inspection equipment — from the 19 contacts and elbow PCB integration of the CBZC2BG-SFEM19-0000 to its shielding and 1.4 kV DC / 1.8 kV DC test voltages, every detail was aligned with the customer’s AOI image acquisition and synchronization system requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.

For more information about our 2B series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.

Building an AOI platform or machine vision control unit? Send us your signal and PCB requirements — our engineering team will respond with a tailored CBZC2BG push-pull connector proposal for your AOI image acquisition systems within 24 hours.
