Push-Pull Connector for Cinema Lighting 2026: CBTG1BG-SMSM03-D420 Plug for High-Output Cinema LED Lighting Umbilicals for Israeli Customers

The CBTG1BG-SMSM03-D420 is a 1B push-pull connector for cinema lighting — a 3-pin plug linking portable battery ballast units to on-set LED lighting panels, delivering a stable, locked and noise-free electricity feed with gold-plated contacts rated for over 5,000 mating cycles. Every specification in this guide is backed by the studio power interconnect engineering of Spring Technology.

Pain point: Powering high-output LED lighting panels on a film set — where portable battery ballast units must feed light panels through a link that stays locked under cable drag, keeps the electricity feed clean and noise-free, and never interrupts a take?

Core answer: For Israeli customers, Spring Technology supplied the CBTG1BG-SMSM03-D420, a 1B series 3-pin push-pull connector for cinema lighting. It links portable battery ballast units to on-set LED lighting panels, ensuring a stable, locked and noise-free electricity feed for high-output cinema lighting.

1. Technical Parameters & Engineering Standards

This cinema lighting connector is built on the TGG.1B straight plug platform, a compact push-pull design trusted in professional equipment. The 3-pin layout carries the power feed between battery ballast units and LED panels.

  • Latching Mechanism: Push-pull self-latching system (anti-vibration & shockproof)
  • Recommended Hardware: Spring Technology Circular Connector
  • Key Metric: Stable, locked and noise-free power feed; 3-pin layout; >5,000 mating cycles
ParameterValue
Connector (this order)CBTG1BG-SMSM03-D420 — TG straight plug, 1B shell, key G, 3-pin solder
SolicitudHigh-output cinema LED lighting umbilicals
LinkPortable battery ballast units to on-set LED lighting panels
Tipo de conectorPlug, male pins
Número de posiciones2–16 pin (1B shell)
TerminaciónSoldar
Tipo de fijaciónEmpujar tirar
Nivel de protecciónIP50
Operating temperature-45 °C ~ +125 °C
Humidity resistanceUp to 95% RH at 60 °C
Vibration / shock10~2000 Hz, 15 g / 100 g·6 ms
Durability> 5,000 mating cycles
Contact finishGold-plated mating contacts
Shell material / finishBrass / Chrome

2. Cinema Lighting Connector Design Highlights

On-set lighting power must stay stable from the battery ballast to the panel. The design highlights below are why this push-pull connector for cinema lighting is specified for high-output LED rigs:

  • Stable, locked connection — the push-pull self-latching mechanism holds the feed locked under cable drag and crew movement around the set.
  • Noise-free electricity feed — clean, low-resistance contacts keep the power feed free of flicker and electrical noise on LED panels.
  • Portable battery ballast link — the 3-pin layout connects portable battery ballast units to on-set LED lighting panels.
  • Gold-plated contacts — stable current path that stays clean across repeated set-ups.
  • Compact 1B shell — lightweight and unobtrusive on lighting cables and ballast units.
  • Proven durability — >5,000 mating cycles for daily rigging and striking on location.

3. 1B Series Connector Family Overview

The 1B series is Spring Technology’s mid-size push-pull connector family, trusted across professional equipment, instruments and control systems. The same 1B platform serves this cinema lighting connector and scales across studio and field power applications.

3.1 Available Configurations

  • Plugs: straight plugs (this order), elbow plugs, plugs with bend relief, in 1B shell size.
  • Pin counts: 2 to 16 pins, with solder termination.
  • Sockets: fixed sockets, free sockets and panel sockets for ballast and panel mounting.
  • Keying: key G standard, with keys A–M and R available for segregation.

3.2 Customization Services

  • Custom pin allocations and part numbers (such as the CBTG1BG-SMSM03-D420) matched to each lighting system’s power plan.
  • Pre-wired umbilical assemblies for battery ballast and LED panel links.
  • Key orientation selection to keep power circuits segregated.
  • Cable entry options for flexible on-set routing.

4. Applications: Cinema LED Lighting Umbilicals

High-output LED lighting has changed how sets are powered. This push-pull connector for cinema lighting keeps the power feed between battery ballast units and panels stable on every take.

4.1 Portable Battery Ballast Units

Portable battery ballast units supply power where mains are unavailable. The CBTG1BG-SMSM03-D420 links these units to the lighting rig with a locked, stable connection.

4.2 On-Set LED Lighting Panels

High-output LED panels draw a clean, stable feed to hold color and output through a take. This connector delivers the noise-free power link the panels need.

4.3 Location Lighting Power Distribution

On location, lighting cables are rigged and struck repeatedly. The durable, gold-plated contacts of this plug keep the feed reliable through the whole production day.

5. Frequently Asked Questions (FAQ)

Q1: What does this plug connect?

**Answer:** It links portable battery ballast units to on-set LED lighting panels, ensuring a stable, locked and noise-free electricity feed.

**Answer:** The push-pull self-latching mechanism keeps the power feed locked under cable drag and crew movement, preventing accidental disconnects that would interrupt a take. Discover reliable options from a certified vendor like [Spring Technology](https://www.spring-connectors.com/).

**Answer:** Yes. Gold-plated, low-resistance contacts keep the electricity feed stable and noise-free, so high-output LED panels hold clean output without flicker.

**Answer:** Yes. Spring Technology offers custom pin allocations, key orientations, pre-wired umbilical assemblies and cable entry options on the 1B platform.

**Answer:** Contact Spring Technology via email at [email protected] or [email protected] with your lighting power requirements and quantities, and the engineering team will respond with a tailored proposal.

Conclusion & Call to Action

This 1B connector delivery for Israeli customers shows how Spring Technology serves the cinema lighting industry — from the CBTG1BG-SMSM03-D420 plug to its matching socket, every detail was aligned with the customer’s high-output LED lighting requirements. Spring Technology also provides professional customization services for both push-pull connectors and cable assemblies, offering tailored solutions to meet your specific technical requirements.

For more information about our 1B series connectors or to discuss your requirements, contact us at [email protected] or [email protected], or visit our website.

Building a battery-powered lighting rig? Send us your power requirements and quantities — our engineering team will respond with a tailored push-pull connector proposal for your cinema lighting within 24 hours.
